KEMET’s New Patent for Solid Electrolytic Capacitor

Solid electrolytic capacitor and method of manufacture

Abstract

An improved solid electrolytic capacitor and method of forming a solid electrolytic capacitor is described. The method includes forming an anode comprising a valve metal or conductive oxide of a valve metal wherein an anode lead extension protrudes from the anode. A dielectric is formed on the anode and a cathode layer is formed on the dielectric. The anode, dielectric, and cathode layer are encased in a non-conducting material and the anode lead extension is exposed outside of the encasement at a side surface. A conductive metal layer is adhered to the anode lead extension which allows termination preferably by electrically connecting a preformed solid metal terminal, most preferably an L shaped terminal, to the conductive metal layer at the side surface.

Read more here.
